EXTERIOR VIEW
Wine Cellar 168 Grand · V168 SSStainless Steel
WINE CELLAR & BEVERAGE REFRIGERATION
Controlled temperature.
Considered presentation.
PKI designs and manufactures wine storage, display and beverage refrigeration for restaurants, hotels, retailers and private residences — from standalone cabinets to fully customized cellar rooms.
CUSTOM-BUILT IN THAILAND
Made to suit the space, capacity and character of each project.
Configurations can be developed around the required bottle capacity, temperature range, shelving system, glass treatment, finish and installation conditions.
Discuss your projectWINE CELLAR · 168 BOTTLES
Wine Cellar 168 Grand
Model: V168 SS
Premium single-temperature wine cellar with stainless steel trim, designed for stable storage and elegant presentation of up to 168 bottles.
BUILT-IN VIEW
Wine Cellar 168 Grand · V168 SSSingle Cabinet Built-in Installation
SPECIFICATIONS · V168 SS
- Measurement
- W 59.5 × D 68 × H 181.2 cm
- Shelves
- 16 removable wooden shelves on safety rails
- Door
- Triple-temperature glass door, anti-UVA
- Capacity
- 430 Liters
- Display
- Digital control and LED
- Feet
- 4 adjustable feet
- No-Frost
- Yes
- Cooling System
- Compressor with direct cooling and fan
- Humidity
- > 65%
- Temperature Range
- +5 to +20 °C
- Temperature Zone
- 1
- Colour
- Black cabinet with stainless steel trims, white glass
- Energy Consumption
- 180 kWh/year
- Climate Class
- SN / N / ST
- Sound Level
- 43 dB
- Wine Bottle Loading
- 168 bottles
Stable Storage
Temperature management designed around wine preservation and operating conditions.
Flexible Capacity
From compact display cabinets to walk-in rooms and large custom installations.
Premium Presentation
Glass, stainless steel, lighting and shelving can be coordinated with the project interior.
OEM / Project Support
Specification development and production support for distributors, designers and contractors.
WINE CELLAR PROJECT ENQUIRY
